Rear Top Luggage Rack For Suzuki DRZ400S 2000-2024 DRZ400SM 2005-2024
Features:
- The rack bolts to four factory holes in your subframe. Two of the holes where for the tool bag.
- The other two are for the stock tail light. You will only be using 4 of the spacers for the install.
- The length of spacer will depend if you are using the stock tail light or not.
- When you are ready for adventure motorcycle riding, this is ready to make it easier and more enjoyable!
- Enlarge box place space for flat and stable placing.
- With this you can easily and safely carry your lugguge.
Item Specifics:
- Brand: Nicecnc
- Type: Top Rack
- Condition: Brand new
- Material: Aluminum
- Color: Black
Package Included:
2x 34.92mm spacers (rear of rack for use with stock tail light)
2x 25.40mm spacers (rear of rack for use with aftermarket tail light)
2x 15.87mm spacers (front of rack closest ro seat)
2x 60mm bolts (rear)
2x 45mm bolts (front)
4x lock nuts
4x washers
Fitment:
For Suzuki DRZ400S 2000-2024
For Suzuki DRZ400SM 2005-2024
For Kawasaki KLX400 2003-2008
Notice:
You will need to drill the rear holes 1/2".
Mark the hole by threading the bolts through the rear holes upside down with the fender installed and either hit the fender with a hammer or paint the top of the bolt.
This will leave a mark on the underside of the fender to drilling.
Disclaimer:
Nicecnc parts are not sponsored or endorsed by, or affiliated with the brands its parts fit, including KTM, Husqvarna, Honda, Yamaha, Kawasaki, Suzuki, Beta, GASGAS, Sherco, etc.
